4.4
Item No. Part Number Qty. Description
ENGINE MOUNTING - CUMMINS
(S/N 9180 and After)
1 8262139 1 Engine, Cummins 4BT 3.9 Turbo
2 8035100 1 Belt, Fan
3 8272017 1 Fan, 18" Suction
4 8310364 4 HHCS, M10-1,5 x 90mm
5 8307023 4 Washer, Lock M10
6 8270220 1 Fan, Alternator
7 8270221 1 Alternator, 65 Amp
8 8310109 2 Nut, Hex Lock Elastic 7/16-14
9 7121951 2 Washer, Rebound 7/16"
10 8307025 14 Washer, Lock M12
11 8303790 6 HHCS, M12-1,75 x 30mm PC 8,8
12 7127562 1 Mount, Engine, Rear Left Side
13 8278021 2 Mount, Engine
14 8303675 4 HHCS, 3/8-16 x 1-1/4" Gr. 5
15 8307110 16 Washer, Flat 3/8" Narrow
16 8305645 8 Nut, Hex Lock Elastic 3/8-16
17 8307113 2 Washer, Flat 7/16" Narrow
18 8310289 2 HHCS, 7/16-14 x 3-1/4" Gr. 8
19 8310333 2 HHCS, 5/8-11 x 4" Gr. 8
20 8307107 2 Washer, Flat 5/8" Narrow
21 8303621 4 HHCS, 3/8-16 x 1-1/2" Gr. 5
22 8278022 2 Mount, Engine
23 7127492 1 Mount, Engine, Front Left Side
24 8310164 8 HHCS, M12-1,75 x 40mm PC 8,8
25 7132141 2 Washer, Rebound 5/8"
26 8305643 2 Nut, Hex Lock Elastic 5/8-11
27 7127462 1 Mount, Engine, Front Right Side
28 7127552 1 Mount, Engine, Rear Right Side
29 8320262 1 Filter, Engine Oil (Also Included In Kits, Items 36 & 37)
30 8035278 1 Starter
31 7131753 1 Mount, Starter Relay
32 8305624 2 Nut, Hex Lock Elastic 1/4-20
33 8277162 1 Relay, Starter (S/N 10964 and After)
7138510 1 Kit, Sealed Relay (S/N 10963 and Before)
34 8310026 2 HHCS, 1/4-20 x 3/4"
35 8277161 1 Heater, Coolant
KITS
36 7138288 1 250 Hour Filter Kit (Includes 2 Filters; Engine Oil Filter & Fuel Filter)
37 7138298 1 1000 Hour Filter Kit (Includes 6 Filters; Engine Oil Filter, Fuel Filter, Both Air Filters,
Transmission Oil Filter & Hydraulic Oil Filter)
3606 Origin 1/00
