4.12
Item No. Part Number Qty. Description
FUEL SYSTEM
(Cummins)
1 8320270 1 Filter, Fuel (Also Included In Filter Kits, Items 32 & 33)
2 8430007 1 Connector, Straight Barb #6-4P
3 8410009 10 Clamp, Hose, SAE Type F
4 7132131 1 Hose, Fuel 3/8 x 10"
5 8274022 1 Strainer, Fuel
6 7132121 1 Hose, Fuel 3/8 x 85" (Fuel Supply From Tank)
7 8430093 1 Connector 3/8" Hose (See Item 31 Note)
8 8541404 1 Plug, Square Hd. Black MI #6P (See Item 31 Note)
9 7120613 1 Sender, Fuel w/Gasket
10 7131992 1 Cover, Fuel Sender
11 8307003 5 Washer, Lock #10
12 8303837 4 Screw, Pan Hd. #10-24 x 3/4"
13 8303836 1 Screw, Pan Hd. #10-24 x 5/8"
14 7129111 1 Hose, Fuel Breather
15 8430072 1 Tee, Beaded, Hose
16 7129101 1 Hose, Fuel Breather
17 7128602 1 Filler, Fuel
18 8275209 1 Clamp, Muffler, U Type 2"
19 8322036 1 Cap, Fuel w/Keys (Includes Item 20)
20 8035292 1 Keys (Set of Two)
21 8405104 1 Clamp, Hose, Upper SAE Type F
22 7129133 1 Hose, Fuel Filler
23 8405202 1 Clamp, Hose, Lower SAE Type F
24 7138736 1 Tank, Fuel
25 8430095 2 Elbow, 5/8" (See Item 31 Note)
26 5724742 2 Gasket
27 7129121 1 Hose, Fuel Breather
28 8430094 1 Elbow, 5/16" Hose (See Item 31 Note)
29 8405009 2 Clamp, Hose, Minature 7/32" Dia.
30 7132111 1 Hose, Fuel Return
31 8526015 AR Sealant, Pipe Thread w/Teflon 8oz (Note: To Be Used With ALL Threaded Fittings)
32 8660011 3 Grommet, 5/8" Fitting
33 8660010 2 Grommet, 3/8" Fitting
34 8430092 1 Drain, Hex - 3/8"-18 NPT
KITS
35 7138288 1 250 Hour Filter Kit (Includes 2 Filters; Engine Oil Filter & Fuel Filter)
36 7138298 1 1000 Hour Filter Kit (Includes 6 Filters; Engine Oil Filter, Fuel Filter, Both Air Filters,
Transmission Oil Filter & Hydraulic Oil Filter)
3606 Rev. 3/02
