Page 73
3.24
Item No.
Part Number
BRAKE ASSEMBLY - FRONT AXLE
NOTE: Quantities listed below are for one complete axle
1
8033575
2
Quadring
2
8035196
4
Quadring
3
8035197
2
Piston, Brake (Positive)
4
8035198
2
Plate, Drive
5
8035199
6
Disc, Brake
6
8035200
6
Plate, Drive
7
8035201
2
Sleeve
8
8035216
2
Kit, Self-Adjust (Includes Items 9 thru 13)
9
NSS
3
Washer, Belleville
10
NSS
3
Pin, Split
11
NSS
3
Spacer
12
NSS
18
Washer, Belleville
13
NSS
3
Bolt
14
8035207
2
Ring
15
8035208
2
Sleeve
16
8035209
4
Washer, Belleville
17
8035210
2
Piston, Brake (Negative)
18
8035211
2
Quadring
19
8035212
6
Washer
20
8035213
6
O-Ring
21
8035214
6
Shaft
22
8035215
6
O-Ring
3606
Origin
7/98
