6.10
Item No.
Part Number
Qty.
FRAME TILT/STABILIZER CYLINDER
1
7134593
1
Cylinder, Frame Tilt/Stabilizer (Includes Items 2 thru 16)
2
N.S.S.
1
Tube
3
8035322
1
Nut, Lock 1.50-12 NF
4
See Kits
2
Precision Wearband
5
8035323
1
Piston
6
See Kits
1
Type 730 Capped T-Seal
7
See Kits
1
O-Ring
8
See Kits
1
O-Ring
9
See Kits
1
Backup Ring
10
See Kits
1
O-Ring
11
See Kits
1
Precision Wearband
12
See Kits
1
Deep Z-Seal with Rod Backup
13
See Kits
1
Locking Insert
14
8035324
1
Head Gland
15
See Kits
1
HD Rod Wiper, Sealed OD
16
8035328
1
Rod Weldment
KITS
17
8035326
1
Seal Kit (Includes Items 4, 6-13 & 15)
3606
Rev
4/02
