2.14
Item No. Part Number Qty. Description
THROTTLE PEDAL CONTROL
(Perkins)
1 8162003 1 Pedal, Throttle (Includes Item 2)
2 8033178 1 Bellows, Throttle Pedal
3 8303615 3 HHCS, 1/4-20 x 1-1/4"
4 8307002 3 Washer, Lock 1/4"
5 8307109 5 Washer, Flat SAE 1/4 Narrow
6 8305402 2 Nut, Hex Jam 1/4-28 NF
7 8700116 1 Spring, Extension
8 8160073 1 Cable, Throttle
9 7128252 1 Bracket, Throttle
10 8303837 2 Screw, Slotted Pan Hd. #10-24 x 3/4"
11 8162213 2 Shim
12 8160610 1 Clamp, Cable
13 8307003 2 Washer, Lock #10
14 8305002 2 Nut, Hex #10-24
15 8340034 1 Rod End 1/4-28 Thd.
16 8305650 1 Nut, Hex Lock Elastic 1/4-28 NF
3606 Rev 5/99
