Transfer box gears and shafts – SkyTrak 3606 Parts Manual User Manual
Page 59
3.10
Item No.
Part Number
Qty.
Description
TRANSFER BOX GEARS AND SHAFTS
1
8841031
1
Transfer Box Assembly (Consists of Items 2 thru 29)
2
8035243
3
Plug, Oil M22-1,5
3
8033608
1
Washer
4
8033613
1
Bolt
5
8033609
1
Washer
6
8033612
1
Breather, M10-1
7
8033619
1
Extension, Breather
8
8033610
1
Washer
9
8035244
1
Shaft
10
8033624
1
Ring, Oil Seal
11
8033625
1
Bearing
12
8033633
4
Gear Z=37
13
8033632
2
Pin, Gear
14
8033626
2
Bearing
15
8033614
2
Plug
16
8033611
1
O-Ring
17
8033594
1
Bearing
18
8033591
1
Ring, Oil Seal
19
8033599
1
Spacer
20
8033603
5
Bolt, M10 x 30mm
21
8033620
1
Cover, Drop Box
22
8033590
1
Nut, Ring M25-1,5
23
8033596
1
O-Ring
24
8033597
1
Ring, Centering
25
8033595
1
O-Ring
26
8035245
1
Flange
27
8033615
AR
Shim, 0,10mm
28
8033616
AR
Shim, 0,19mm
29
8033617
AR
Shim, 0,35mm
3606
Origin
7/98
