Main frame, Covers and guards – SkyTrak 3606 Parts Manual User Manual
Page 11
1.4
Item No.
Part Number
Qty.
Description
COVERS AND GUARDS
1
7130814
1
Hood, Engine
2
7129922
1
Hinge, Hood - Rear
3
7125731
4
Moulding, Black 7" Long
4
8307110
6
Washer, Flat 3/8" Narrow
5
8303540
6
HHCS, 1/4-20 x 1"
6
7129912
1
Hinge, Hood - Front
7
7131782
2
Retainer Ring, Latch
8
6620002
1
Moulding, Black 16" Long
9
8342807
1
Latch w/Key (Includes Item 10)
10
8342808
AR
Key
11
8702157
2
Spring, Clip
12
8340035
2
Ball Stud - 13mm
13
8307106
24
Washer, Flat 5/16"
14
8305626
10
Nut, Hex Lock Elastic 5/16-18
15
8702156
1
Spring, Gas
16
7130072
1
Support, Cover
17
8303739
2
HHCS, 5/16-18 x 1-1/4"
18
8302406
2
Pin, Cotter
19
8310334
2
Pin, Clevis 3/8" Dia.
20
7132844
1
Panel, Engine
21
8303679
4
HHCS, 3/8-16 x 1-3/4" Gr.5
22
8303670
14
HHCS, 5/16-18 x 1"
23
8307004
14
Washer, Lock 5/16"
24
7129663
1
Cover, Engine, Rear
25
8305906
10
Nut, Retainer 5/16-18
26
8305645
4
Nut, Hex Lock Elastic 3/8-16
27
7129653
1
Cover, Engine, Front
28
8303744
4
HHCS, 5/16-18 x 1/2"
29
7129612
1
Bracket, Cover - Front
30
7129622
1
Bracket, Cover - Rear
31
7131652
2
Striker, Rear Door
32
8702158
1
Spring, Gas
33
8340036
2
Ball Stud - 10mm
34
7130173
1
Cover, Rear
35
8342416
2
Latch, Adjustable Trigger
36
8307112
2
Washer, Flat 1/2" Heavy
37
8305644
2
Nut, Hex Lock Elastic 1/2-13
38
8303625
2
HHCS, 1/2-13 x 1-1/4"
39
8307109
4
Washer, Flat SAE Light 1/4"
40
8305624
8
Nut, Hex Lock Elastic 1/4-20
41
8307202
4
Washer, Flat 1/4"
42
8303114
2
HHCS, 1/4-20 x 2-1/4" Gr.5
43
7134132
2
Hook, Rubber
44
7134122
2
Bracket, Anchor
45
7134142
2
Bracket, Hook
46
8303836
4
Screw, Slotted Pan Hd. #10-24 x 5/8"
47
8307111
4
Washer, Flat #10
48
8310085
4
Nut, Hex Lock Elastic #10-24
3606
Rev
9/99
