Page 105
4.2
Item No.
Part Number
Qty.
Description
ENGINE MOUNTING - CUMMINS
(S/N 9179 and Before)
1
8262139
1
Engine, Cummins 4BT 3.9 Turbo
2
8035100
1
Belt, Fan
3
8272017
1
Fan, 18" Suction
4
8310364
4
HHCS, M10-1,5 x 90mm
5
8307023
4
Washer, Lock M10
6
8270220
1
Fan, Alternator
7
8270221
1
Alternator, 65 Amp
8
8770077
2
Connector, Straight, #10 ORB x #12 Flat Face
9
8770080
2
Elbow, Swivel 90 °, #12 Flat Face
10
2715082
2
Hose Assembly, Remote Oil Filter
11
8584003
1
Tie Wrap
12
8310109
2
Nut, Hex Lock Elastic 7/16-14
13
7121951
2
Washer, Rebound 7/16"
14
8307025
16
Washer, Lock M12
15
8303790
6
HHCS, M12-1,75 x 30mm PC 8,8
16
7127562
1
Mount, Engine, Rear Left Side
17
8278021
2
Mount, Engine
18
8303675
4
HHCS, 3/8-16 x 1-1/4" Gr. 5
19
8307110
16
Washer, Flat 3/8" Narrow
20
8305645
8
Nut, Hex Lock Elastic 3/8-16
21
8307113
2
Washer, Flat 7/16" Narrow
22
8310289
2
HHCS, 7/16-14 x 3-1/4" Gr. 8
23
8310333
2
HHCS, 5/8-11 x 4" Gr. 8
24
8307107
2
Washer, Flat 5/8" Narrow
25
8303621
4
HHCS, 3/8-16 x 1-1/2" Gr. 5
26
8278022
2
Mount, Engine
27
7127492
1
Mount, Engine, Front Left Side
28
8310164
8
HHCS, M12-1,75 x 40mm PC 8,8
29
7132141
2
Washer, Rebound 5/8"
30
8305643
2
Nut, Hex Lock Elastic 5/8-11
31
7127462
1
Mount, Engine, Front Right Side
32
7127552
1
Mount, Engine, Rear Right Side
33
8320262
1
Filter, Engine Oil (Also Included In Filter Kits, Items 45 & 46)
34
8770079
2
Elbow, 90 °, #12 ORB x #12 Flat Face
35
7128592
1
Bracket, Oil Filter
36
8307002
2
Washer, Lock 1/4"
37
8303729
2
HHCS, 1/4-20 x 5/8"
38
8303618
2
HHCS, M12-1,75 x 25mm
39
8035278
1
Starter
40
7131753
1
Mount, Starter Relay
41
8305624
2
Nut, Hex Lock Elastic 1/4-20
42
8277162
1
Relay, Starter (S/N 10964 and After)
7138510
1
Kit, Sealed Relay (S/N 10963 and Before)
43
8310026
2
HHCS, 1/4-20 x 3/4"
44
8277161
1
Heater, Coolant
KITS
45
7138288
1
250 Hour Filter Kit (Includes 2 Filters; Engine Oil Filter & Fuel Filter)
46
7138298
1
1000 Hour Filter Kit (Includes 6 Filters; Engine Oil Filter, Fuel Filter, Both Air Filters,
Transmission Oil Filter & Hydraulic Oil Filter)
3606
Rev
1/00
