SkyTrak 3606 Parts Manual - Manual (Page 167)

6.14
Item No. Part Number Qty. Description
HOIST CYLINDER
1 2716562 1 Cylinder, Hoist w/Bearing (Includes Items 2 thru 18)
2 8902271 1 Counterbalance Valve - Set at 4000 psi (276 bar)
3 N.S.S. 1 Tube
4 8035308 1 Nut, Lock 2.00-12 UN
5 See Kits 2 Precision Wearband
6 8035309 1 Piston
7 See Kits 1 Capped T-Seal
8 See Kits 1 O-Ring
9 See Kits 1 O-Ring
10 See Kits 1 Backup Ring
11 See Kits 1 O-Ring
12 See Kits 2 Precision Wearband
13 See Kits 1 Deep Z-Seal with Rod Backup
14 8035310 1 Head Gland
15 See Kits 2 Locking Insert
16 See Kits 1 HD Rod Wiper, Sealed OD
17 8065640 1 Bearing, Self Align
18 8035311 1 Rod Weldment
19 8520013 1 Fitting, Lube, Self Tapping 1/8 NPT
KITS
20 8035312 1 Seal Kit (Includes Items 5, 7-13 & 15-16)
21 8205656 1 Seal Kit (For Item 2)
3606 Rev 4/02
