6.24
Item No. Part Number Qty. Description
MAIN CONTROL VALVE
(Boom Raise/Lower & Extend/Retract Sections)
1 8902167 1 Main Control Valve Assembly (Includes Items 2 thru 42)
2 8035347 1 Nut, Special - Upper
3 8035381 2 Nut, Special - Lower
4 8035380 1 Tie Rod, Upper
5 8035379 2 Tie Rod, Lower
6 8034539 1 Plug Assembly, Shut Off - Orifice
7 8035342 1 Outlet Section Assembly
8 8035341 1 Section Assembly - Boom Extend/Retract (Includes Items 10 thru 25)
9 8035341 1 Section Assembly - Boom Raise/Lower (Includes Items 10 thru 26)
10 8035377 2 Capscrew, Socket Hd.
11 8035368 2 Retainer
12 8035370 1 Cap, Spool
13 8035362 1 Screw, Shoulder Socket Hd.
14 8035361 2 Washer, Flat
15 8035355 1 Spring
16 8035360 1 Spacer
17 See Kits 1 O-Ring
18 8035378 1 Retainer, Spool Cap
19 See Kits 2 O-Ring
20 8034697 1 O-Ring (See Kits)
21 8035364 1 Shuttle
22 8035369 1 Cap, Spool
23 8035350 2 Capscrew, Socket Hd.
24 8035367 1 Poppet
25 8035358 1 Spring
26 8035363 1 Anti - Void Assembly
27 8035354 2 Relief Valve Assembly - Preset at 3750 ±50 psi (258 ±3,5 bar)
(Includes Items 29 thru 36)
28 8034538 1 Relief Valve Assembly - Preset at 3200 ±50 psi (220 bar ±3,5 bar)
(Includes Items 29 thru 36)
29 See Kits 2 O-Ring
30 See Kits 2 O-Ring
31 See Kits 1 O-Ring
32 See Kits 2 Ring, Back Up
33 See Kits 1 Spring
34 See Kits 1 Spring
35 See Kits 1 Ring, Back Up
36 See Kits 1 Spring
37 8035340 1 Mid Inlet Section Assembly (Includes Items 38 thru 40)
38 See Kits 1 O-Ring
39 8034697 1 O-Ring
40 8035364 1 Shuttle
41 8035382 1 Plug Assembly - SAE
42 See Kits 1 O-Ring
KITS
43 8035384 1 Seal Kit, Entire Valve (Includes Items 17, 19, 20 & 42 and Additional Items On
“Main Control Valve Attachment Tilt & Frame Tilt Sections”)
44 8034540 1 Seal & Spring Kit, Relief Valve (Includes Items 29 thru 36)
3606 Rev 9/99
