Page 89: 4 speed)
3.40
Item No.
Part Number
Qty.
Description
CHARGING PUMP, DRIVE, FILTER & REVERSE IDLER
(4 Speed)
1
8034983
2
Thrust Washer, Pump Drive Idler
2
8034984
1
Bearing, Idler Gear
3
8034985
1
Gear, Pump Drive Idler (31T)
4
8034986
1
Pump Drive Idler Shaft And Pin Assembly (Includes Item 5)
5
8034987
1
Pin, Roll
6
8034988
1
Bearing, Pump Drive Gear
7
8034989
1
Gear, Pump Drive (34T)
8
8034990
1
Bearing, Pump Drive Gear
9
8034996
2
Gasket, Adaptor
10
8034997
1
Adaptor, Pump To Plate
11
8034998
1
Stud, Pump Mounting
12
8034999
5
Washer, Lock - Pump Mounting Stud
13
8035000
5
Nut, Pump Mounting Stud
14
8035001
4
Stud, Pump Mounting
15
8035090
1
Pump, Charging
16
8035002
1
Nut, Pump Mounting
17
8034934
1
Washer, Lock - Pump Mounting Stud
18
8035003
1
Stud, Pump Mounting
19
8035004
1
Filter Assembly (Also Included in Filter Kit, Item 40)
20
8035009
1
Regulator Valve Assembly (Includes Items 21 thru 24)
21
8035005
1
Piston
22
8035006
1
Spring
23
8035007
1
Pin
24
8035008
1
Sleeve
25
8035016
1
Capscrew, Reverse Idler End Plate
26
8035015
1
Washer, End Plate Capscrew
27
8035017
1
Roll Pin, End Plate To Shaft
28
8035014
1
Plate, End
29
8034917
1
Gear, Reverse Idler (28T)
30
8035013
1
Bearing, Reverse Idler Gear
31
8035012
1
Washer, Thrust
32
8035011
1
Shaft, Idler And Pilot
33
8035010
1
Snap Ring, Idler Shaft
34
8034992
1
Ball Check Valve Assembly (Includes Items 35 thru 38)
35
8034991
1
O-Ring
36
8034993
1
Pin
37
8034994
1
Ball
38
8034995
1
Spring
KITS
39
8035089
1
Transmission Gasket And Sealing Kit (Services Entire Transmission)
40
7138298
1
1000 Hour Filter Kit for Cummins Turbo (Includes 6 Filters; Engine Oil Filter,
Fuel Filter, Both Air Filters, Transmission Oil Filter & Hydraulic Oil Filter
7138299
1
1000 Hour Filter Kit for Perkins Natural (Includes 6 Filters; Engine Oil Filter,
Fuel Filter, Both Air Filters, Transmission Oil Filter & Hydraulic Oil Filter
7138432
1
1000 Hour Filter Kit for Perkins Turbo (Includes 6 Filters; Engine Oil Filter,
Fuel Filter, Both Air Filters, Transmission Oil Filter & Hydraulic Oil Filter
3606
Rev
9/99
