Page 141
5.14
Item No.
Part Number
Qty.
SERVICE BRAKE & DE-CLUTCH CIRCUIT
1
8902164
1
Valve, Brake
2
8770068
1
Elbow, 90°, SAE 6 - str. thd. ORB x o-ring face seal
3
8770111
1
Tee, Swivel Run, SAE 6 - o-ring face seal
4
8770105
1
Elbow, 90° Swivel, SAE 6 - o-ring face seal
5
8430081
1
Nipple, Diagnostic
6
8430032
3
Plug, Dust
7
8902169
1
Manifold, Auxiliary Function
8
8770106
2
Connector, SAE 6 - str. thd. ORB x o-ring face seal
9
8430043
2
Nipple, Diagnostic 9/16-18
10
8770114
1
Elbow, 90°, SAE 8 - str. thd. ORB x o-ring face seal
11
7129582
1
Bracket, Bulkhead Fitting
12
2715452
1
Hose, 1/2" I.D. x 17" Long
13
2715442
1
Hose, 3/8" I.D. x 106" Long
14
2715402
1
Hose, 1" I.D. x 62" Long
15
2715392
1
Hose, 1" I.D. x 19.3" Long
16
2715342
3
Hose, 3/8" I.D. x 32" Long
17
2715212
1
Hose, 3/8" I.D. x 136-1/2" Long
18
2715202
1
Hose, 3/8" I.D. x 81" Long
19
2715192
1
Hose, 3/8" I.D. x 111" Long
20
8770091
1
Cap, SAE 16 - o-ring face seal
21
8770093
1
Tee, Male Run, SAE 16 - ORFS tube end x str. thd. o-ring
22
8770097
7
Elbow, 90° Swivel, SAE 4 - o-ring face seal
23
8770100
4
Tee, Swivel Run, SAE 4 - o-ring face seal
24
8770116
1
Connector, SAE 8 - str. thd. ORB x o-ring face seal
25
8902691
6
Connector, M10-4 - metric str. thd. ORB x o-ring face seal
26
8770069
1
Connector, SAE 6-8 - str. thd. ORB x o-ring face seal
27
8770096
1
Nut, Bulkhead, SAE 16 - o-ring face seal
28
8770095
1
Elbow, 90°, Bulkhead, SAE 16 - o-ring face seal
29
8770098
1
Cap, SAE 4 - o-ring face seal
30
2715262
1
Hose, 3/8" I.D. x 81-1/2" Long
3606 Origin 7/98
