38
Duration of pulse The duration of the output signal
Until Reset
The output will remain high after a valid trigger, until the channel is
reset
Inverted Output Check the box to set the output high until a valid trigger.
On the Triggering tab choose:
Normal The channel can retrigger an unlimited number of times
Skip N triggers The channel triggers only after the specified number of valid input
pulses (between 0 and 2,147,483,647).
Retrigger N times Limits the number of retriggers allowed between resets (between 0 and
2,147,483,647). To allow a channel to be triggered again after reaching
the limit, press the Reset button on the Model 725 or choose Program
> Reset Channels in timerPRO.
Trigger on input high While the input is high, channel can be repeatedly triggered.
Trigger on rising input Sets the channel to be edge triggered (i.e., an input signal that stays
high will only trigger the channel once).
The front panel LED for the noise suppression channel will glow green until an input signal is
detected. It will then glow red until the duration period has elapsed. At this point, the LED will
respond as follows:
Retriggering
enabled? Edge
trigger? LED
no yes or no remains red (no more triggers accepted)
yes no glows green (waiting for next trigger)
yes yes is off; glows green when trigger goes low
