19
It is important to distinguish between the eight physical input jacks, in1–in8, and the eight timing
channel inputs. Any combination of the physical inputs can be used to trigger the channel inputs.
The following assignment is incorrect:
outA = in1;
because it attempts to trigger a channel output rather than a channel input, inA–inH
This assignment is also invalid:
in1 = in2;
because it attempts to assign a value to External Input 1.
Finally, this assignment is invalid:
inB = inA;
because it attempts to assign a value from one channel input to another.
Parsing
When you have completed a logical assignment, click the Apply button. timerPRO will check
your syntax and logic and will report any mistakes to you by line number.
Sending Logic
If you change channel logic you must transfer those changes to the Model 725 to implement them.
To transfer logic to the Model 725, click the Set All Channels button
, or choose
Program >Program All Channels.
While the logic is transferring, the Power LED on the Model 725 will turn red. This transfer
typically takes only a second, though it may take slightly longer for complex programs.
After the transfer, the logic settings reside in the Model 725, even if you turn the unit off or
disconnect it from the PC.
