Then click OK. With this logic, Channel A will trigger when you depress the external
trigger button (connected via BNC cable).
5. Now transfer the logic to the Model 725 by clicking the Set All Channels button .
6. Plug an oscilloscope to Output A to observe the channel output. Remember, the output
voltage will vary from 0 to 5 V.
“Apply” versus “Program All Channels”
Each properties screen includes an Apply button which, when clicked, will send the current
timing properties to the channel on the Model 725.
NOTE: If you change a channel’s properties, closing the Settings screen will have the
same effect as clicking Apply. Clicking the OK button will also have the same effect.
Logic settings are sent and saved in the Model 725, but any changes are not implemented on the
Model 725 until you click Set All Channels button or choose Program>Program All Channels.
Program All Channels is the same as clicking Apply for all channels and then instructing the
Model 725 to update its logic programming.
The Cancel button cancels any edits made since the last time the Apply button was clicked and
closes the dialog window.
