1. Menu
options:
The File menu lets you open, close and save experiment files (.trg files).
The Edit Menu lets you cut, copy and paste text as you edit your program.
The View menu lets you set up the timerPRO interface. Choose to display or hide the
tool bars and status bar, select the font used in timerPRO, and set up communications
with the Model 725.
The
Channel menu lets you open the screens for General Settings and for each of the
eight channels.
The
Program menu includes options for communicating with the Model 725. You can
send logic, send properties, reset all channels, or enable/ disable the Model 725’s inputs
and outputs.
2.
The buttons are as follows:
The General Settings button
opens the General Settings screen.
The
Channel buttons open the Settings screens for all channels.
The Program button
updates the Model 725 with all current settings.
The Reset button
resets all channels of the Model 725. Retriggering Counters and
delay settings will be reset as well.
The Main window panel shows a text summary of all of the settings in the current
experiment. This summary may be printed for review and documentation purposes. The
text is not freely editable and must be modified through the dialogs. Double-clicking on
selected parts of the summary opens the dialog needed to edit the text.
At any time, the Model 725 control bar can be hidden or displayed by clicking View > Model
725.
