11
SOFTWARE INTERFACE
timerPRO has been designed exclusively for setup and control of the Model 725. You’ll use
timerPRO to set the timing properties and logic for each of the eight channels and to set up
overall properties for the experiment.
Main Screen
When you run timerPRO, you’ll be greeted by the Main screen:
NOTE: At start-up, the Main screen will show the default program, which sets
all channels to Delayed Pulse After Trigger mode.
From this screen you’ll control or access all of timerPRO’s functions. Most timerPRO functions
can be accessed in two ways by selecting an option from a pull-down menu or by pressing a
button on the Main screen.
