ARB 5650010 User Manual
Page 4
Last Rev Date: 16/10/2006
Page 4 of 25
3783210 - rev 3
Copyright © 2005 by ARB Corporation Limited. All rights reserved, this document must not be reproduced without the express authority of ARB Corporation Ltd
USE PART
No
QTY
DESCRIPTION
319 9850
1
PLATE CHASSIS BEAM
615 1300
2
CAGE NUT M6
615 1017
2
BOLT M6 x 16 mm LONG
615 1046
2
FLAT WASHER M6
615 1042
2
SPRING WASHER M6
615 1306
2
CAGE NUT M12 SHORT LEG
615 1340
2
BOLT M12 x 50 mm
458 1049
2
FLAT WASHER M12
BACKING PLATE TO
CHASSIS BEAM.
458 1050
2
SPRING WASHER M12
615 1330
1
NUT M20 NYLOC
615 1329
1
BOLT M20 x 190 mm LONG
636 4506
1
BUSH – ARM ASSY
WHEEL CARRIER TO
REAR BAR.
625 0002
2
SPACER THIN – 9 mm THICK
180 302
4
CABLE TIES - BLACK
MISC ITEMS TO REAR BAR
AND WHEEL CARRIER.
458 1299
5
WASHER FLAT NYLON
375 6909
1
WHEEL MOUNTING BRACKET
615 1382
3
WHEEL STUDS ½ “ WITH WHEEL NUT
615 1305
2
CAGE NUTS M12 LONG LEG
615 1355
2
BOLT M12 x 35 mm LONG
458 1007
2
PANEL WASHER M12 GOLD
458 1050
2
SPRING WASHER M12
615 1357
1
BOLT M10 x 30 mm LONG ( WITH WASHERS )
WHEEL MOUNTING PLATE
TO WHEEL CARRIER.
WHEEL MOUNTING PLATE
TO WHEEL CARRIER
PINNING BOLT .
458 1063
1
FLANGE NUT M10
615 1301
4
CAGE NUTS M8 LONG LEG
615 1234
4
BOLT M8 x 25 mm LONG BLACK
458 1047
4
SPRING WASHER M8 BLACK
458 1045
4
FLAT WASHER M8 BLACK
682 1195
1
REAR DOOR BLANKING GROMMET
6821194
1
TWIN CORE CABLE - 750 mm LONG
CR 07
1
CONVOLUTE TUBING - 7 mm x 750 mm LONG
320 104N
1
TAIL LAMP HOUSING WIRING GROMMET
666 005
1
RING TERMINAL
180 701
1
SCOTCH LOCK CONNECTOR
HIGH LEVEL STOP LAMP TO
WHEEL CARRIER .
HIGH LEVEL STOP LAMP
WIRING LOOM EXTENSION
TO TAIL LAMP ON VEHICLE
.
180 302
6
CABLE TIES - BLACK
455 8424
1
COVER PANEL
615 1300
4
CAGE NUT M6
615 1312
2
SOCKET HEAD CAP SCREW M6 x 25 mm LONG
615 1270
2
BOLT M6 x 40 mm LONG
615 1046
4
FLAT WASHER M6
458 1036
4
SPRING WASHER M6
584 8302
2
PACKER BLACK NYLON
COVER PANEL FITMENT TO
REAR BAR.
625 0003
2
SPACER 8 mm THICK
