USE PART No QTY DESCRIPTION
566 5677 1 SLIDER
682 1116 2 SQUARE PLASTIC PLUG
FITTING SLIDER TO
REAR STEP.
615 1283 2 SELF TAPPING SCREWS
459 0007 1 CATCH HOOK
615 1303 2 CAGE NUT M8 SHORT LEG
615 1022 2 BOLT M8 x 25 mm LONG
458 1046 2 SPRING WASHER M8
458 1044 2 FLAT WASHER M8
FITTING CATCH HOOK TO
REAR BAR.
3756746 2 PACKER CATCH HOOK
584 8322 1 BUMP STOP
615 1312 2 M6 BUTTON HEAD CAP SCREW x 25 mm
FITTING BUMP STOP TO
REAR BAR.
615 1162 2 M6 NUT NYLOC
375 6677 1 GRABBER
615 1303 2 CAGE NUT M8 SHORT LEG
615 1022 2 BOLT M8 x 25 mm LONG
458 1046 2 SPRING WASHER M8
FITTING GRABBER TO
REAR BAR.
458 1063 2 PANEL WASHER M8
PIVOT LOCKING BOLT 615 1222 1 BOLT LOCKING M8 x 50 mm LONG (FINE PITCH)
459 0011 1 CATCH ASSEMBLY
615 1263 4 SOCKET HEAD CAP SCREWS M8 x 20 mm LONG
458 1046 4 SPRING WASHERS M8
626 0002 1 STOPPER
458 1046 1 SPRING WASHER M8
458 1044 1 FLAT WASHER M8
615 1028 1 NUT M8
626 0001 1 GRABBER BUFFER
615 1331 2 CAP SCREW COUNTERSUNK M6 x 30 mm LONG
615 1162 2 NUT NYLOC M6
459 0001 1 GAS STRUT ASSY (inc 1 strut, 2 clips, 2 spheres)
615 1132 2 NUT FLANGED M8
458 1044 2 FLAT WASHER M8
459 0008 1 LOCKING PIN
459 0009 1 LOCKING PIN SPRING
INSTALLATION OF
COMPONENTS TO WHEEL
CARRIER.
459 0010 1 ROLL PIN
375 6886 R 1 BRACKET RIGHT HAND
375 6886 L 1 BRACKET LEFT HAND
REINFORCING BRACKET
FITMENT TO CHASSIS.
615 1291 6 TAB BOLT M12 x 40 mm LONG FINE PITCH
458 1049 22 FLAT WASHER M12
458 1050 14 SPRING WASHER M12
615 1135 6 NUT M12 FINE PITCH
615 1250 2 BOLT M12 x 90 mm LONG COARSE PITCH
472 1570 2 DIA 17 mm CRUSH TUBE x 60 LONG
615 1255 4 BOLT M12 x 40 mm LONG COARSE PITCH
615 1189 8 NUT M12 COARSE PITCH
REINFORCING BRACKET
FITMENT TO CHASSIS
CONTINUED.
615 1340 2 BOLT M12 x 50 mm COARSE PITCH
