GENERAL CARE AND MAINTENANCE

choosing an ARB Bar, you have bought a product that is one of the most sought after 4WD products

in the world. Your bar is a properly engineered, reliable, quality accessory that represents excellent
value. To keep your bar in original condition it is important to care and maintain it following these
recommendations:

Prior to exposure to the weather your bar should be treated to a Canuba based polish on all exposed

surfaces. It is recommended that this is performed on a six monthly basis or following exposure to
salt, mud, sand or other contaminants.

As part of any Pre Trip Preparation, or on an annual basis, it is recommended that a thorough visual

inspection of the bar is carried out, making sure that all bolts and other components are torqued to
the correct specification. Also check that all wiring sheaths, connectors, and fittings are free of
damage. Replace any components as necessary. This service can be performed by your local
authorised ARB Stockist.

REQUIRED TOOLS FOR FITMENT OF PRODUCT:

METRIC SOCKET SET, METRIC RING AND OPEN ENDED SPANNER SET, PHILLIPS AND FLAT SCREW
DRIVER SET, ELECTRIC DRILL AND METRIC DRILL BITS 6 mm, 13 mm AND 17 mm, LARGE HAMMER,
CENTRE PUNCH, HEX KEY SET, PIN PUNCH, GREASE, METAL SCRIBE .

WIRE CUTTERS , SOLDERING IRON & SOLDER, INSULATING TAPE AND ELECTRICAL TERMINAL CRIMPERS
( IF RE-CONNECTING THE FACTORY HI LEVEL STOP LAMP ).

NOTE :- The bearings & seals for the wheel carrier are available as spare parts.

PART No

QTY

DESCRIPTION

732 0003

SEAL

732 0002

BEARING

HAVE AVAILABLE THESE SAFETY ITEMS WHEN FITTING PRODUCT

Protective eyewear

Hearing protection

NOTE: ‘WARNING’ notes in the fitting procedure relate to OHS situations, where to avoid a potentially
hazardous situation it is suggested that protective safety gear be worn or a safe work procedure be
employed. If these notes and warnings are not heeded, injury may result.

FASTENER TORQUE SETTINGS:

SIZE

Torque Nm

Torque lbft

9 Nm

4 lbft

22 Nm

16 lbft

M10

44 Nm

32 lbft

M12

77 Nm

57 lbft

Last Rev Date: 16/10/2006

Page 2 of 25

3783210 - rev 3
