PAUSE Key Self Test
This self test can be used to provide the test labels required when making
adjustments to the printer’s mechanical assemblies. See the sample printout
in Figure 34.
1. Turn off the printer.
2. Press and hold the PAUSE key while turning on the power.
n
The initial self test prints 15 labels at 2.4"/61 mm per second
(1”/25.4 mm for the 600X-PLUS) per second, then automatically pauses
the printer. Each time the PAUSE key is pressed, an additional 15 labels
print.
n
While the printer is paused, pressing the CANCEL key alters the self
test. Now each time the PAUSE key is pressed the printer prints 15
labels at 6"/152 mm per second (4”/102 mm for the 600X-PLUS).
n
While the printer is paused, pressing the CANCEL key again alters the
self test again. Each time the PAUSE key is pressed the printer prints 50
labels at 2.4”/61 mm per second (1”/25.4 mm for the 600X-PLUS).
n
While the printer is paused, pressing the CANCEL key again alters the
self test a third time. Now each time the PAUSE key is pressed the
printer prints 50 labels at 6”/152 mm per second (4”/102 mm for the
600X-PLUS).
n
While the printer is paused, pressing the CANCEL key again alters the
self test a fourth time. Each time the PAUSE key is pressed the printer
prints 15 labels at the printer’s maximum speed.
n
To exit this self test at any time, press and hold the CANCEL key.
Brady X-PLUS Series User’s Guide 83
Figure 34
