Fanfold Media Loading
NOTE: A calibration must be performed when media and ribbon (if used)
are first installed in the printer, or when a different type of media
or ribbon is being used.
Fanfold media feeds through either the bottom or rear access slot from
outside the printer.
Refer to Figures 21 and 22.
1. Open the printhead.
2. Slide the media guide as far from the printer frame as possible.
3. Load media as shown. If in cutter mode, route media through the
cutter.
4. Slide in the media guide so it just touches, but not restricts, the edge of
the roll.
5. Close the printhead.
