Loading the Media
Figure 5 illustrates one method of media loading. For more detailed
instructions, as well as information about how to load the different types of
media and the various printing modes, refer to the instructions that begin on
page 27.
Brady X-PLUS Series User’s Guide
9
Media
guide
Media
Media
supply
guide
Closed
Open
Printhead lever
Tear-off/
peel-off
bar
Figure 5
