Brady X-PLUS Series User’s Guide

55

Press

Display Shows

Action/Explanation

NETWORK ID

Setting Network ID

Press the LEFT BLACK OVAL key to

move to the next digit position, press the RIGHT BLACK OVAL

key to increase the value of the digit.
Default: 000
Range: 000 - 999
Network ID is used to assign a unique number to a printer used in

an RS-422/RS-485 network. This gives the host the means to

address a specific printer. If the printer is used in a network, you

must select a network ID number. This does not affect TCP/IP or

IPX networks.

COMMUNI-

CATIONS

Setting Communications Mode

Press the RIGHT or LEFT

BLACK OVAL key to display other choices.
Default: Normal mode
Selections: Normal mode, diagnostics
The communication diagnostics mode is a troubleshooting tool

for checking the interconnection between the printer and the

host. When “diagnostics” is selected, all data sent from the host

to the printer will be printed as straight ASCII hex characters. The

printer prints all characters received including control codes, like

CR (carriage return). A sample printout is shown in Figure 36 on

page 85.
NOTES on diagnostic printouts:
• An FE indicates a framing error.
• An OE indicates an overrun error.
• A PE indicates a parity error.
• An NE indicates noise.
For any errors, check that your communication parameters are

correct. Set the print width equal to or less than the label width

used for the test. See page 48 for more information.
