Brady 300X-PLUS - Manual (Page 40)

Cutter Mode
NOTE: Cutter option required.
Refer to Figure 19.
1. Open the printhead.
2. Slide the media guide and media supply guide as far from the printer
frame as possible. Flip down the media supply guide.
3. Load media as shown.
4. Flip up the media supply guide. Slide in the media guide and media
supply guide so they just touch, but not restrict, the edge of the roll.
5. Close the printhead.
6. The printer will automatically feed out and cut one label when the
printer is turned on.
32 Brady X-PLUS Series User’s Guide
