¾ COS only: The port will follow the COS priority assigned
¾ TOS only: The port will follow the TOS priority assigned
¾ COS first: The port will follow COS priority first, and then another
priority rule
¾ TOS first: The port will follow TOS priority first, and then another
priority rule
„ COS priority: Set the COS priority level 0~7
„ TOS priority: The system provides 0 to 63 TOS priority levels. Each
level has 4 types of priority – high, mid, low, and lowest. The default
value is “Lowest”. When the IP packet is received, the system will check
the TOS value.
[NOTE] QoS and Rate control cannot be used simultaneously.
