VLAN—Port Base Add interface
4. The VLAN group will be displayed after apply is clicked
5. Click Next Page to view the next VLAN group
6. Use Delete button to delete unwanted VLANs
7. Use Edit button to modify existing VLANs
[NOTE] If the configuration is not saved, it will be lost when the switch
is powered off
802.1Q VLAN
Tagged-based VLAN is an IEEE 802.1Q specification which allows VLANs
to be created across devices from different venders. IEEE 802.1Q VLAN
