893-01010-A A-1
Appendix A
Technical Specifications
General Specifications
Network Protocol Ethernet
Fast Ethernet
Standards Supported 802.1d
802.3i, 10BASE-T
802.3u, 100BASE-T
Data rate
BayStack 303 switch: 24 10Mb/s port
One 10/100Mb/s port
One optional 10/100BASE-TX or 100BASE-FX
port
BayStack 304 switch: 12 10Mb/s port
One 10/100Mb/s port
One optional 10/100BASE-TX or 100BASE-FX
port
Electrical Specifications
Input current: 1.5 to 0.6 Amps
Input voltage (rms): 90 to 250 VAC @ 47 to 63 Hz
Power consumption: 60 W maximum
Environmental Specifications
Operating temperature: 0
°
to 40
°
C (32
°
to 104
°
F)
Storage temperature: –25
°
to 70
°
C (–13
°
to 158
°
F)
Operating humidity: 85% maximum relative humidity, noncondensing
Storage humidity: 95% maximum relative humidity, noncondensing
Operating altitude: 3024 m (10,000 ft)
