Using the BayStack 303 and 304 Ethernet Switches
2-16 893-01010-A
Selecting a Language
The BayStack 303 and 304 switches are designed to interface with the user in one
of seven languages. Selection of a user interface language is done from the
language menu, shown in
Figure 2-8 . The language menu is displayed at the
initial power-up sequence and whenever the system is reset to default values. At
all other times, the Main Menu is displayed when the switch is turned on.
To select a language for the user interface, enter the number corresponding to the
chosen language and the Main Menu is displayed in the selected language.
Figure 2-8. Language selection menu
Forward Delay 15 seconds
Max Age 20 seconds
Bridge Priority 32768
Port Priority 128
Port Path Cost 0
Trap Receiver # Community Name and
IP Address (1, 2, 3, & 4) Public - 0.0.0.0
Table 2-1. Factory default settings (continued)
Parameter Default value
1 ---English
2 ---French/Francais
3 ---German/Deutsche
4 ---Japanese
5 ---Spanish/Espanol
6 ---Italian/Italiano
7 ---Chinese
Current Selection:
Please enter number for selection:
