Installing the BayStack Switches
893-01010-A 2-15
Initial Setup of a BayStack Ethernet Switch
In most cases, the BayStack 303 and 304 Ethernet Switches can be installed and
made operational using the system default settings.
Minimal configuration is required when you plan on remote management or TFTP
operations. In that case, you need to enter the IP address of the switch, the subnet
mask, and the gateway address. Refer to
Chapter 3, “Customizing and Managing
the BayStack Switches ,” for more information about configuring your BayStack
303 or 304 switch.
Using Factory Default Settings
When you turn on power to the switch, it begins operation using the factory
default settings for configuration parameters.
Table 2-1 lists default values for the
parameters.
Table 2-1. Factory default settings
Parameter Default value
Language None
IP Address 127.0.0.2
IP Subnet Mask Address 255.255.255.0
Default Gateway Address 0.0.0.0
Spanning Tree Protocol Enabled
Telnet Access Enabled
Authentication Trap Generation Enabled
Password (Telnet) No password assigned
Port Path Cost 0
Port Priority 128
High Speed Port Half or Full Duplex Half Duplex
High Speed Port Speed Auto
Spanning Tree Priority 32768
Active Aging Time 300 seconds
Designated Root 32768 - 00.00.00.00.00.00
Hello Time 2 seconds
