Installing the BayStack Switches
893-01010-A
2-17
Initial Switch Setup
The BayStack switches are designed for plug-and-play operation; however,
certain parameters must be configured in order for the switch management
function to become fully operational. After the language has been selected, the
Main Menu is displayed (see
Figure 2-9.
Main Menu
*****************************************************************************
Bay Networks BayStack 303 Ethernet Switch
IP Address:
[0.0.0.0]
Mac Address:
[00:00:81:12:12:12]
Software Version:
[1.0]
System Up Time:
[0d:00h:00m:00s]
Switch Status:
[Switching]
*****************************************************************************
Main Menu
1 -- System Information
2 -- System Configuration
3 -- Reset System
4 -- Exit Telnet
Enter Command ([ESC]---Previous Screen [Space]---Refresh Screen)
