Customizing and Managing the BayStack Switches
893-01010-A
3-7
System Information
The System Information screen displays the current parameter settings for the
switch. All of the screens associated with system information are read only. To
change any parameter or setting you must go through the System Configuration
menu.
The System Information screen provides three paths to switch statistics and status
information. The following options are available from the System Information
Screen:
•
Switch Information
•
Spanning Tree Information
•
Port Statistics and Status Information
Switch Information
The Switch Information screen displays the following switch parameter settings:
•
SNMP Read Community String: public
•
SNMP Read/Write Community String: private
•
Authentication Trap: [Disabled]
•
LinkUp/LinkDown Trap: [Disabled]
•
Trap Receiver 1 IP and Community Name: [0.0.0.0] [public]
•
Trap Receiver 2 IP and Community Name: [0.0.0.0] [public]
•
Trap Receiver 3 IP and Community Name: [0.0.0.0] [public]
•
Trap Receiver 4 IP and Community Name: [0.0.0.0] [public]
•
Spanning Tree Mode: [Enabled]
•
Telnet Access: [ ]
Spanning Tree Information
The Spanning Tree statistics and information are divided into two areas:
•
Spanning Tree General Information
•
Spanning Tree Port Information
