Using the BayStack 303 and 304 Ethernet Switches
2-18 893-01010-A
To set the IP address, subnet mask, and gateway address for the switch, follow
these steps:
1. Type 2 to select 2---System Configuration from the Main Menu.
This selection displays the System Configuration menu (see Figure 2-10 ).
Figure 2-10. System Configuration menu
*****************************************************************************
Bay Networks BayStack 303 Ethernet Switch
IP Address: [0.0.0.0]
Mac Address: [00:00:81:12:12:12]
Software Version: [1.0]
System Up Time: [0d:00h:00m:00s]
Switch Status: [Switching]
*****************************************************************************
System Configuration
1 -- Switch Network Configuration
2 -- Port Configuration
3 -- Spanning Tree Configuration
4 ---SNMP Configuration
5 -- Reset to Default
Enter Command ([ESC]---Previous Screen [Space]---Refresh Screen)
