42
e
Hold the SO-DIMM by the edges and
align the notches in the SO-DIMM with
the protrusions in the slot. Insert the
SO-DIMM diagonally (1), then tilt it
toward the interface board until it clicks
into place (2).
f
Put the metal (2) and then the plastic (1)
SO-DIMM covers back on.
g
Plug the machine’s power cord back into
the electrical socket first, and then
connect the interface cable.
h
Turn on the machine’s power switch.
Note
To make sure that you have installed the
SO-DIMM correctly, you can print the user
settings page that shows the current
memory size. (See User Settings List
on page 98.)
1 2
1
2
