Pioneer X-SMC5-K - Manual (Page 42)

Playable discs and files on discs or USB storage devices 14
42
En
Regarding copy protected CDs
This unit is designed to conform to the specifications of the
audio CD format. This unit does not support the playback or
function of discs that do not conform to these specifications.
About playing DualDiscs
A DualDisc is a new two-sided disc, one side of which
contains DVD content - video, audio, etc. - while the other side
contains non-DVD content such as digital audio material.
• The DVD side of a DualDisc can be played on this unit
(excluding any DVD-Audio content).
• The non-DVD, audio side of the disc is not compatible
with this unit.
• It is possible that when loading or ejecting a DualDisc,
the opposite side to that being played will be scratched.
Scratched discs may not be playable.
• For more detailed information on DualDisc
specifications, please refer to the disc manufacturer or
disc retailer.
Playing discs created on computers or BD/DVD
recorders
• It may not be possible to play discs recorded using a
computer due to the application settings or computer’s
environment settings. Record discs in a format playable
on this unit. For details, contact the dealer.
• It may not be possible to play discs recorded using a
computer or a BD/DVD recorder, if burn quality is not
good due to characteristics of the disc, scratches, dirt on
the disc, dirt on the recorder’s lens, etc.
Playable files
• Only discs recorded in ISO9660 Level 1, Level 2 and Joliet
can be played.
• Files protected by DRM (Digital Rights Management)
cannot be played.
• No warranty is provided regarding the ability to play
WMV and MPEG-4 AAC files recorded on disc media
(DVD-R/-RW/-R DL and CD-R/-RW/-ROM).
Supported video file formats
DivX
• DivX is a media technology created by DivX, Inc. DivX
media files contain image data.
• DivX files may also include such advanced playback
functions as menu screens and selection of multiple
subtitle languages/ audio tracks.
• DivX Certified ® to play DivX ® video, including premium
content.
• DivX ® , DivX Certified ® and associated logos are
trademarks of DivX, Inc. and are used under license.
File extensions: .avi and .divx (these must be used for this
unit to recognize DivX video files). Note that all files with the
.avi extension are recognized as MPEG4, but not all of these
are necessarily DivX video files and therefore may not be
playable on this unit.
• Files not containing DivX video signals cannot be
played, even if they have the extension “.avi”.
Supported file resolutions include the following:
• NTSC: up to 720 x 480
• PAL: up to 720 x 576
Displaying external subtitle files
• The font sets listed below are available for external
subtitle files. You can see the proper font set on-screen
by setting the Subtitle Language on page 34 to match
the subtitle file.
• This unit supports the following language groups:
• Some external subtitle files may be displayed incorrectly
or not at all.
• For external subtitle files the following subtitle format
filename extensions are supported (please note that
these files are not shown within the disc navigation
menu): .srt, .sub, .ssa, .smi
• The filename of the movie file has to be repeated at the
beginning of the filename for the external subtitle file.
• The number of external subtitle files which can be
switched for the same movie file is limited to a maximum
of 10.
Supported image file formats
JPEG
Resolution: Up to 3072 x 2048 pixels
File extensions: .jpg and .JPG (must be used for this unit to
recognize JPEG files - do not use for other file types)
• This unit supports baseline JPEG.
• This unit supports Exif Ver.2.2.
• This unit does not support progressive JPEG.
Group 1 Afrikaans (af), Basque (eu), Catalan (ca), Danish
(da), Dutch (nl), English (en), Faroese (fo), Finnish
(fi), French (fr), German (de), Icelandic (is), Irish
(ga), Italian (it), Norwegian (no), Portuguese (pt),
Rhaeto-Romanic (rm), Scottish (gd), Spanish (es),
Swedish (sv)
Group 2 Albanian (sq), Croatian (hr), Czech (cs), Hungarian
(hu), Polish (pl), Romanian (ro), Slovak (sk),
Slovenian (sl)
Group 3 Bulgarian (bg), Byelorussian (be), Macedonian
(mk), Russian (ru), Serbian (sr), Ukrainian (uk)
Group 4 Hebrew (iw), Yiddish (ji)
Group 5 Turkish (tr)
