BUSH HOG / MATERIAL HANDLING REPAIR PARTS MANUAL
14-13-37
REF. PART
NO. NO. QTY. DESCRIPTION
1 —— 2 Hex Nut 7/8” CP
2 —— 2 Lockwasher 7/8” CP
3 —— 2 Capscrew 7/8” x 2” G5 ZP
4 0461086 2 Jack Clip Pin
5 50034870 2 Lock Pin
6 50049412 4 Spacer Bushing
7 50005860 2 Cotter, Hair Pin
8 50032825 2 3-Point Lower Pin
9 50053597 1 Instruction Sheet
10 —— 4 Hex Nut 5/8” CP G5 CP
11 —— 4 Lockwasher 5/8” CP
12 —— 4 Capscrew 5/8” x 1-3/4” G5 ZP
13 50053576 1 Front Mount Weldment
14 50053565 1 Front Hanger Weldment
15 —— 2 Hex Nut 7/8” CP
16 —— 2 Lockwasher 7/8” CP
17 —— 2 Capscrew 7/8” x 2-1/2” G5 ZP
18 50034919 2 Brace
19 50053589 1 L.H. Rail Weldment
20 50053588 1 R.H. Rail Weldment
21 44332 4 Capscrew M12 x 1.75 x 110
22 44200 4 Lockwasher M12
23 44269 4 Flatwasher M12
24 44896 2 Capscrew 3/4” x 2” NF
25 –––– 2 Lockwasher 3/4”
26 44897 2 Hex Nut 3/4” NF
8
BACKHOE
MAINFRAME
50053587 SUBFRAME KIT
Bush Hog 650, 750, 850 Backhoes
Used on Massey Ferguson 1547-FWA, 1552-FWA
Agco ST47A-FWA, ST52A-FWA Tractors
with BH M300, GB 2153, MFG 1530 or AGCO SL48A Loader Mounts
19
16
11
7
15
1
2
13
18
18
17
24
25
26
23
22
21
3
20
6
12
10
4
5
14
CAU ION Be o e l av ng ra t r s at s op en i e o k br ke re eve yd au c
p es u e a d r m ve k y
CAU ION Do Not l ow b s and rs n wo k a ea
INSTALLAT ON NOTES • Re ove l m un ng r c e s r m r e R f r o F g 1 on P ge 2 o n u e ha a l om o en s ave e n nc de ) • C e n th e d d ho es n he r c or ame w h a t p o t e pr p r s ze Pa t ru t nd or eb s
in h t r ads m y c use o t to m s l gn r n t i h en or e t y
• T is ou t g k t as o h s a d rd nd m t c as e e s su e h t he r pe f s e e s a e u ed n he o r ct
oc i ns Re e to ig 2 n Pa e 2 as n a d o d n i i g c r e t a t n r )
• L ave l mo n i g ha dw re ose n i mou t ng t s com l e y i s a ed • A t r he m u t g k t n a l i n s c mp e e t g en a ha d a e o t e s ec c t o s g en n he b t o q e ch rt
on age 6 • A t r he r t ou a d t en f e e e y 4 h u s or he st ay f o e a on a l m un ng a dw r sh u d b ch c ed
f r r pe t r ue p c i a ons
Pa e 1 01 0 / 4 02 3 n r c on S e t No 5 04 9 0
OR TRAC OR MO ELS JOHN DEERE ® 770 790
FOR MOUN I G Bush Hog 6 0 / 7 0 BackHoe G eat Bend 2165 / 2175 BackHoe
BUSH HOG GREAT BEND
SUBFRAME AT ACH NG KIT 5004 534
Us ng Bu h og M146 oa er a d or G ea Bend 125 L ad r
9
JUNE, 2008
