BUSH HOG / MATERIAL HANDLING REPAIR PARTS MANUAL
14-12-1
50033414 DECAL KIT FOR BH650
50033541 DECAL KIT FOR BH750
50033458 DECAL KIT FOR BH850
50033506 DECAL KIT FOR BH950
50102298
IMPORTANT
IMPROPER HYDRAULIC HOOK-
UP CAN CAUSE SERIOUS
DAMAGE TO VALVE
• REFER TO ATTACHING KIT OR
PTO PUMP KIT MANUAL FOR
PROPER HYDRAULIC HOOK-UP.
• NEVER PRESSURIZE RETURN
PORT OF VALVE OR RESTRICT
RETURN HOSE.
• ALWAYS MOVE TRACTOR
3-POINT HITCH CONTROL TO
FULLY LOWERED POSTION
WHILE BACKHOE IS
MOUNTED TO TRACTOR.
50102296
IMPORTANT
IMPROPER HYDRAULIC HOOK-
UP CAN CAUSE SERIOUS
DAMAGE TO VALVE
• REFER TO ATTACHING KIT OR
PTO PUMP KIT MANUAL FOR
PROPER HYDRAULIC HOOK-UP.
• NEVER PRESSURIZE RETURN
PORT OF VALVE OR RESTRICT
RETURN HOSE.
• ALWAYS MOVE TRACTOR
3-POINT HITCH CONTROL TO
FULLY LOWERED POSTION
WHILE BACKHOE IS
MOUNTED TO TRACTOR.
50102296
To avoid serious injury or death:
Do not operate this backhoe unless
it is rigidly attached to the tactor using
the appropriate factory - provided
mounting kit. Do not mount backhoe
on a 3-point "Quick Attaching Coupler".
50102293
50102293
CRUSHING HAZARD
DANGER
DO NOT OPERATE 3 POINT RIGID MOUNT
BACKHOE UNLESS HITCH AND STAB LIZER
BARS ARE INSTALLED PROPERLY. FAILURE TO
DO SO MAY RESULT IN SERIOUS INJURY OR
DEATH FROM BACKHOE BE NG THRUST
UPWARD BY DIGGING FORCES CRUSHING
OPERATOR.
OPERATOR S AREA (SHADED AREA OF 40"
RAD US FROM SEAT TO 10" BEHIND SEAT)
MUST BE FREE FROM ALL OBSTRUCTIONS.
USE ONLY SPECIAL HITCH PARTS SUPPLIED
WITH BACKHOE. SEE OPERATOR S MANUAL
FOR PROPER ASSEMBLY AND ADJUSTMENT
OF HITCH.
10" M N
40" MIN
RAD OUS
TOP LINK
STABILIZER BARS
50102292
50102292
50033051
50102294 (BH650)
50033476 (BH750)
50102523 (BH850)
50033477 (BH950)
50033282
12115
50033364
50102297
50033216
50033427
50102296 50102295
50100238
50033426
50036633
BH650
BH750
BH850
BH950
OCTOBER, 2003
50033366
