14-13-1
BUSH HOG / MATERIAL HANDLING REPAIR PARTS MANUAL
10
21
11 7
22
24
25
26
3
11
4
19
17
16
18
15
Bush Hog
Loader Mount
12
2
20
5 REF. PART
NO. NO. QTY. DESCRIPTION
1 45017 4 Capscrew 1/2” NF x 3-1/2” Gr.5 ZP NF
2 15032 6 Capscrew 5/8” NF x 2” Gr.5 ZP
3 15046 2 Capscrew 7/8” NF x 2” Gr.5
4 –––– 2 Capscrew 7/8” NC x 2-1/2” Gr.5 ZP
5 20964 4 Locknut 1/2” NF CP Center
6 44743 6 Hex Nut 5/8” NF CP
7 44061 2 Hex Nut 7/8” NF CP Class 2B
8 –––– 2 Hex Nut 7/8” CP
9 –––– 6 Lockwasher 5/8” CP
10 50032825 2 3 Point Lower Pin
11 –––– 4 Lockwasher 7/8” CP
12 50020926 8 Fatwasher 1/2” SAE Hardened ZP
13 0461086 2 Hair Pin Clip #6
14 50034866 2 Spacer
15 50034867 2 Front Hanger Weldment
16 50045934 1 R.H. Frame Rail Weldment
17 50045935 1 L.H. Frame Rail Weldment
18 50034870 2 Lock Pin
19 50035322 1 Brace R.H.
20 50034862 1 Cross Support Weldment
21 50005860 2 Cotter, Hair Pin
22 50034865 1 Brace, L.H.
23 50034873 1 Instruction Sheet
24 44896 2 Capscrew 3/4” x 2” NF
25 –––– 2 Lockwasher 3/4”
26 44897 2 Hex Nut 3/4” NF
50045936 SUBFRAME KIT
For Bush Hog Backhoe Models BH650, BH750
Used on Ford/New Holland TC35, TC35A, TC35D, TC35DA, TC40, TC40A,TC40D,
TC40DA, TC45, TC45A, TC45D & TC45DA Tractors
and Case/IH D35, DX35, D40, DX40, D45 & DX45 Tractors
with Bush Hog 2346 QT Loader or Great Bend 284 Loader.
8
14
12
13
1
9
6
23
CAUT ON: e ore e v ng t a to se t st p eng ne ock ra e e eve h d au c
pr ss re a d emo e key
CAUT ON: o ot a ow by t nd rs n work r a
NS ALLAT ON NOTES
• Rem ve l mo n ng b a k t f om r te Re e t F g 1 n P ge 2 o n u e t a a l omp n n s h ve een c u ed) • Cl an h e ded o es n he r c or r me w th t p of he r pe s ze Pa nt u t a d / r d b is
in he h e ds m y ca se o ts o m sa gn r n t t g t n c r e t y
• Th s m un ng t h s b th an a d a d me i f s e e s n u e ha t e p o er s en s a e u ed n he o r ct
l c t o s ( e er o F g 2 on a e 2 as n a d o i e t y n co e t as ne s)
• Le ve l mou t ng a dw re o se u t l ou t ng i is om l t ly n a l d • A t r he m un ng t n t l t o is om e e g t n a l a dw e to h sp c i a o s g v n n t e b l t r ue h rt
on P ge 6
• A t r he r t h u and en a e ev r 4 ho r f r he r t d y o o e a i n a l mo n ng a dw re h u d be h ck d
f r p o er r ue pe f c i ns
age 1 1 01 04 02 03 n t u i n Sh e No 50 4 940
F R RACTOR MODE S JOHN DEERE ® 770 90
FOR MOUNT NG Bush Hog 650 / 750 BackHoe Gr at Bend 2 65 / 175 B ckHoe
BUSH HOG / GREAT BEND
SUBFRAME ATTACH NG KIT 500415 4 U i g Bush H g M 46 L ad r Gr at B nd 2 25 Lo der
JUNE, 2008
