BUSH HOG / MATERIAL HANDLING REPAIR PARTS MANUAL
14-13-25
REF. PART
NO. NO.
QTY. DESCRIPTION
1 44893 4 Capscrew 5/8” x 1-1/2” Gr5 NF
2 15031 6 Capscrew 5/8” x 1-3/4” Gr5 NF
3 44894 4 Capscrew 3/4” x 1-1/2” NF
4 20132 4 Capscrew 7/8” x 3” Gr5
5 15046 4 Capscrew 7/8” x 2” Gr5 NF
6 44743 10 Hex Nut 5/8” NF
7 44897 4 Hex Nut 3/4” NF
8 –––– 2 Hex Nut 7/8”
9 –––– 10 Lockwasher 5/8”
10 –––– 4 Lockwasher 3/4”
11 –––– 6 Lockwasher 7/8”
12 461086 2 Hair Pin Clip #6
13 50034919 2 Brace
14 44212 6 Capscrew M16 x 1.5 x 60 Gr8.8
15 50034870 2 Lock Pin
16 50042603 1 Frame Rail Weldment R.H.
17 50042604 1 Frame Rail Weldment L.H.
18 50042605 1 Rear Hanger Weldment
19 50044760 1 Front Hanger Weldment R.H.
20 50042607 1 Front Hanger Weldment L.H.
21 50042608 1 Front Mount Weldment
22 44061 4 Hex Nut 7/8” NF
23 44099 6 Lockwasher M16
24 –––– 2 Flatwasher 7/8”
25 50042628 1 Instruction Sheet
25
50042627 SUBFRAME KIT
For Bush Hog BH650 & BH750 Backhoes
Used on Kubota L3130, L3430, L3830 Tractors
with Bush Hog M246,
Kubota LA513 and LA273,
and Great Bend 2130 Loaders
Replaced by 50045927 Subframe Kit
22
13
1
4
5
22
5
3
17
9
10
6
7
16
18
23
19
20
14
21
9 6
12
15
2
11
13
11
8
11
AUGUST, 2005
C UT ON: Be o e eav ng r c or s at s op e g ne l ck b ake r l e e hy ra l c re su e nd r move ey
C UT ON: Do No a l w ys an e s in wo k a ea
INSTALLATION NOTES • R mo e a l m u t n b ac e s om c a e ( e er o F g 1 on a e 2 to su e h t a c mpo e ts a e b en n l d d) • C e n t r a ed h l s in h t a t r f am wi h a ap f t e p op r i e P nt r st nd o de r s n t e t r a s may au e bo s t mi a i n or ot gh en o r c ly • T s mo n i g k has o h s nd r and m r c a t n rs I s re h t he r p r a t ne s re s d in e co e t
o a ons Re r o F g 2 on P ge 2 s an id o d n f ng o r ct s en s)
• L a e a l m un ng h r wa e l o e un l mo n i g k t s c mp e e y ns a ed • A er e mo n i g k t s a a on s c mp e e i h en l h r wa e o he pe f c i ns i en n he o t o q e c a t
o Pa e 6
• A er e f s ho r nd he a t r e e y 4 ou s o t e f s da of p r t on ll ou t g ha wa e s o ld e c e ked o p op r o q e s ec ca o s
P ge 1 0 / 1 04 7 2 03 I s uc on he t No 00 1 40
FOR TRA TOR MODELS JOHN DEERE ® 7 0 790
OR M UNT NG Bush Hog 650 750 Ba kHoe Great Bend 2165 / 2175 BackHoe
BUSH HOG / GREAT BEND
SUBFRAME ATTACHING K T 5 041534 Us ng B sh Hog M1 6 Lo der nd / or G e t Be d 125 oa er
