BUSH HOG / MATERIAL HANDLING REPAIR PARTS MANUAL
14-13-56
REF. PART
NO. NO. QTY. DESCRIPTION
1 50005860 2 Cotter, Hair Pin
2 —— 2 Lockwasher 7/8” CP
3 44200 4 Lockwasher M12 ZP
4 44333 4 Capscrew M12 x 1.25 x 55 G8.8 ZP
5 50020926 4 Flatwasher 1/2” SAE HRD ZP
6 —— 2 Hex Nut 7/8” CP
7 —— 2 Capscrew 7/8” x 2” G5 ZP (*Used on
BH750/GB 2175)
8 50034870 2 Lock Pin
9 0461086 2 Jack Clip Pin
10 50032825 2 3 Point Lower Pin
11 50057826 1 Instruction Sheet
12 50057823 1 Subframe Weldment
13 50057824 1 Center Support Weldment
14 50034919 2 Brace
15 —— 2 Lockwasher 3/4”
16 —— 2 Capscrew 7/8” x 2-1/2” G5 ZP
17 —— 2 Lockwasher 7/8” CP
18 —— 2 Hex Nut 7/8” CP
19 44896 2 Capscrew 3/4” x 2” NF G5 ZP
(*Used on BH 665H/GB 652)
20 44897 2 Hex Nut 3/4” NF
10
BH750
BACKHOE
MAINFRAME
12
17
8
CAUT ON B fo e l av ng t a tor eat s op en ine ock b ake re eve h dr ul c p es ure and emove k y
CAUT ON Do No a low by t nde s in wo k ar a
NSTALLATION NOTES
• R mo e a l mo n ng b a ke s r m r te Re e to F g 1 on P ge 2 o ns re h t a l om on n s ha e b en nc u ed) • C e n t r ad d o es n t e t ac or ame w th a ap o t e pr pe s ze P i t r st a d/ r d br s n he t r ads m y cau e bo s to m s l gn o not gh en or e t y • h s mou t g k t h s bo h t nd rd nd me ic a en rs I su e ha t e p op r as e e s a e us d n t e co ect o a ons Re er o F g 2 on P ge 2 as n a d to en f ng c r e t as e e s) • ea e a l mo nt ng ar wa e l ose nt l m un ng k t s com l t ly n t l ed • f er e mou t ng i ns a a on s c mp e e gh en l h r wa e to he pe f c t ns g v n n t e bo t o q e ch rt n Pa e 6 • f er e f st ou and h n a t r e e y 4 ho rs o t e f st ay f o e a i n ll m u t ng a dwa e s o ld e ch c ed o p op r or ue pe i c t o s
P ge 1 1 01 04 02 03 n t u t on he t No 50 41 40
FOR TRAC OR MODE S ® 770 790
FOR MOUN ING Bush Hog 650 / 750 BackHoe G eat Bend 2165 / 2175 BackHoe
BUSH HOG / GREAT BEND
SUBFRAME ATTACH NG KIT 0041534
U ing B sh Hog M146 Lo der a d or Gr at Bend 125 Lo der
11
1
18
13
6
2
9
14
14
16
19*
7*
5
3
4
15
20
50057822 SUBFRAME ATTACHING KIT
BUSH HOG BH750 BACKHOES
For Kubota MX5000 & MX5000 SU Tractors
with BH 2346QT / 3045 or GB 284 / 3045 Loader Mounts
JUNE, 2008
