Bush Hog BH950 - Manual (Page 56)

8
10
2
10
7
20
19
14
4 22
3
3
20
10 8
15
22 11
16
5
TRACTOR
REAR
PLATE
TRACTOR
PIN
21
1
13
9 6
17
12
BUSH HOG
LOADER MOUNT
JOHN DEERE
LOADER MOUNT
14-13-10
50033557 SUBFRAME KIT
for Bush Hog Backhoe Models BH650 & BH750
Used on John Deere 770 and 790 Tractors
with Bush Hog 1846 QT
or Great Bend 220 Loaders
23
REF. PART
NO. NO.
QTY. DESCRIPTION
1 15032 4 Capscrew 5/8” x 2” Gr.5 NF
2 20132 2 Capscrew 7/8” x 3” Gr. 5
3 15046 4 Capscrew 7/8” x 2” Gr. 5 NF
4 44326 4 Capscrew M16 x 2 x 50 Gr.8.8
5 44398 6 Capscrew M16 x 2 x 60 Gr.8.8
6 44743 4 Hex Nut 5/8 NF
7 19503 2 Hex Nut 7/8”
8 44061 4 Hex Nut 7/8” NF
9 19486 4 Lockwasher 5/8”
10 15824 6 Lockwasher 7/8”
11 44308 6 Flatwasher m16
12 0461086 2 Hair Pin Clip #6
13 50035997 2 Guide Plate
14 50034996 1 Rear Hanger R.H.
15 50035995 1 Rear Hanger L.H.
16 50035999 1 Hanger Weldment
17 50036000 1 Front Hanger Weld.
18 50036002 1 Frame Rail Weld. R.H.
19 50036001 1 Frame Rail Weld. L.H.
20 50035998 2 Brace
21 50034870 2 Lock Pin
22 44099 10 Lockwasher M16
23 20571 2 Flatwasher 7/8”
24 50036004 1 Instruction Sheet
24
AUGUST, 2005
CAUT ON: B f re e v ng t ac o se t t p eng ne ock b a e e i ve h d au ic
pr ss re and emo e key
CAUT ON: Do ot a ow by t nde s n ork r a
NSTALLAT ON NOTES • em ve l mo n i g b a k t f om c te Re e to g 1 n P ge 2 o ns r t at l c mp n n s h ve een c u ed) • l an h e ded o es n t e r c or r me w th a p of he ro er ze a nt u t a d / r d b is n he h e ds may a se b l s o m sa gn o no t g t n c r e t y • h s m un ng t h s b th an a d a d me ic s e e s n u e t a t e p o er a en r a e u ed n he c r ct
ca o s (R er o F g 2 on ag 2 as n a d o i e t y ng o ec f s e e s)
• e ve a mou t ng a dw re o se u t l m un ng i is omp t ly n t l d • f r he m un ng i ns l a on s om l e g t n a l a dw re o he p c i a on g v n i t e bo t r ue ha t
n P ge 6
• f r he i t h ur nd h n a er v ry ho rs r he r t d y o op a i n a l mo n ng h r w re ho d be he k d
r p o er r ue s e f c i ns
P ge 1 1 01 04 02 03 n t u t n Sh e No 50 4 940
FOR T ACTOR MODE S ® 70 7 0
FOR MOUNT NG Bush Hog 650 / 750 BackHoe Gr at Bend 2 65 / 175 Ba kHoe
BUSH HOG / GREAT BEND
SUBFRAME ATTACHING K T 500415 4
U i g ush H g M 46 L ad r Gr at B nd 2 25 Lo der
