BUSH HOG / MATERIAL HANDLING REPAIR PARTS MANUAL
14-2-2
BOOM, DIPPERSTICK
& RELATED PARTS
MODEL BH750
REF. PART
NO. NO.
QTY. DESCRIPTION
18 50033160 1 Pin, 1.25 x 6.81”
19 50033162 1 Pin, 1.25 x 10.19”
20 50033174 1 Pin Weldment, Boom
21 50033205 1 Guide Link, RH
22 50033207 1 Guide Link, LH
23 50033210 1 Bucket Link Assembly
24 50033218 1 Hose Clamp
25 50033219 1 SMV Adapter
26 50101986 1 Bar, Sign Mount
27 50102295 1 Decal, Important
28 50033115 1 Plate,Hose Retention
29 –––– 1 Capscrew 5/16” x 5”
30 50033364 1 Decal, Warning
31 –––– 3 Capscrew 3/8” x 2-1/4”
32 50032987 2 Pin 1.00 x 8.00”
33 –––– 2 Capscrew 3/8” x 2-1/4”
34 20363 2 Locknut 3/8”
35 50033112 4 Bushing 1-1/4” x 1” x 1-3/8”
36 50033216 2 Decal, Model BH750
37 50032976 6 Bushing 1-1/4” x 1 x 1.75
38 449 6 Grease Fitting
39 50028063 6 Grease Fitting
40 50057414 2 Bush Hog Decal
41 50033188 1 Hose Clamp
42 –––– 1 Capscrew 5/16” x 3/4”
43 –––– 2 Carriage Bolt 5/16” X 3/4”
44 50100238 3 Decal, Warning
REF. PART
NO. NO.
QTY. DESCRIPTION
1 15602 5 Locknut 5/16”
2 –––– 4 Lockwasher 5/16”
3 –––– 1 Flatwasher 5/16”
4 –––– 5 Capscrew 3/8” x 2-1/2”
5 20363 10 Locknut 3/8”
6 50032807 1 Handle Bushing
7 50032982 2 Pin Weldment, Upper Link
8 50032998 1 Fastener Pin 1” x 8”
9 50033524 1 Boom Weldment w/ Decal
10 50033526 1 Dipper Stick w/ Decal
11 50033528 1 Boom Cylinder w/ Decal
12 50033529 1 Dipper Stick Cylinder w/ Decal
13 50033530 1 Bucket Cylinder w/ Decal
14 50033158 1 Pin 1.25 x 9.56”
15 50033159 1 Pin, 1.25 x 8.50”
16 50033161 1 Pin, 1.25 x 7.93”
17 50033171 1 Pin, 1.00 x 8.12”
43
21
38
44
39
28
37
37
23
35
35
35
22
4
10
9
4
5
7
32 33
34
5
25
26 2 1 24
13
39
31
17
19
5
5
39
44
4 18
4
37
37
41
2
42
39
44
11
12 39
39
4
5 16
40
31
5
30
27
8
14
31
20 6
29
1
2
3
5
15
36
1
See Bucket
and Related
Parts.
38
38
38
38
JULY, 2007
