Chapter 8: Configuring Modem Security
MM701G and MM702G User Manual
79
2
Select
Add Interface
, which is a link below the
Security Interfaces
table, to display the
Firewall Add Interface
page.
3
In the
Name
box, select the session (interface from the
Session Name to Interface Mapping
table shown on
) as the external interface to which NAT is bound.
4
In the
Interface
Type
box, select
external
.
5
Click
Apply
and you automatically return to the
Security Interface Configuration
page.
6
To bind this session with NAT to internal interfaces (private LAN-side IP addresses), click
the button
Enable NAT to internal interfaces
located in the
NAT
column in the
Security
Interfaces
table. To disable the binding of this session with NAT to internal interfaces, click the button
Disable NAT to internal interfaces
located in the
NAT
column in the
Security
Interfaces
table.
In the
Session Name to Interface Mapping
table, the
Session Name
is the name you
assigned to a session during configuration. The Interface is the protocol type
selected for that session and corresponds to the
Name:
field at the top of the
page. NAT is attached to this session which is an external (WAN) interface.
