Table 15. Intel Storage Server SSR212MC2R Boot Drive Cable Connections (continued)
Boot drive options Mini-USB cable P4 power cable Boot drives 12 SAS/SATA drives
SATA DOM Connected to
mini-USB connector
on server board
Connected to SATA
DOM via power
adapter cable
provided with DOM.
Not used Intel RAID Controller
SRCSATAWB
connected to
backplane via
mini-SAS to
mini-SATA cable
USB Header DOM Mini USB cable
removed
Removed from boot
drive backplane.
Not used Intel RAID Controller
SRCSATAWB
connected to
backplane via
mini-SAS to
mini-SATA cable
Internal USB Port Connected to USB
port on server board
Not used Not used Intel RAID Controller
SRCSATAWB
connected to
backplane via
mini-SAS to
mini-SATA cable
Table 16. Intel Storage Server SSR21 2MC2R Boot Drive SAS/SATA Cable Connections
Server board
connector
SATA boot drive (as
shipped) SAS boot drive DOM boot drive
SATA 0 N/A N/A SATA DOM (if
installed)
SATA 1 N/A N/A N/A
SATA 2 / SAS 0 Boot drive (bottom) Boot drive (bottom) Not used
SATA 3 / SAS 1 Boot drive (top) Boot drive (top) Not used
SATA 4 / SAS 2 Not used Not used Not used
SATA 5 / SAS 3 Not used Not used Not used
Installing an add-in board
To install an add-in board, complete the following steps:
Note: You may want to install an operating system before installing any add-in
boards.
CAUTION:
Add-in boards can be extremely sensitive to ESD and always require careful
handling. After removing the board from its protective wrapper, place it
component side up on a grounded, static-free surface or conductive foam pad, if
available. Do not slide the add-in board over any surface.
Attention: Do not overload the server board by installing add-in boards that
draw excessive current.
1. Observe all safety and ESD precautions in the Safety and Warranty Guide.
2. Turn off all peripheral devices connected to the storage array.
3. Turn off the storage array.
4. Disconnect the AC power cord(s).
