If

using

an

optional

SATA

Disk

on

Module

(DOM),

remove

the

P4

power

cable

connected

to

the

DOM’s

power

adapter

cable.

Note:

If

you

are

using

a

SATA

DOM

device,

the

P4

power

cable

is

disconnected

from

the

boot

drive

module

and

connected

to

a

SATA

DOM

.

Power

for

a

USB

DOM

device

is

provided

by

the

USB

connector.

See

13.

Remove

the

USB

or

SATA

DOM

if

one

is

present.

14.

Remove

the

Intel

RAID

Controller

SRCSATAWB.

Disconnect

the

SAS

cable

1 .

Release

the

screw

2

on

the

retaining

bracket

at

the

back

of

the

enclosure.

Lift

the

Intel

RAID

Controller

SRCSATAWB

upwards

and

out

of

the

enclosure 3 .
