Table 14. Intel Storage Server S5000PSL Boot Drive SAS/SATA Cable Connections
Server board
connector
SATA boot drive (as
shipped) SAS boot drive DOM boot drive
SATA 0 Boot drive (bottom) N/A SATA DOM (if
installed)
SATA 1 Boot drive (top) N/A N/A
SATA 2 / SAS 0 Expander (0) Boot drive (bottom) Expander (0)
SATA 3 / SAS 1 Expander (1) Boot drive (top) Expander (1)
SATA 4 / SAS 2 Expander (2) Expander (2) Expander (2)
SATA 5 / SAS 3 Expander (3) Expander (3) Expander (3)
Intel Storage Server SSR212MC2R Boot Drive Options
The Intel Storage Server SSR2 1 2MC2R includes an Intel RAID Controller
SRCSATAWB to support hardware RAID. The twelve SAS/SATA drives plugged
into the backplane are connected to the Intel RAID Controller SRCSAS 144E via the
mini-SAS to mini-SAS cable. The twelve drives can be populated with either SAS
or SATA drives. See the Tested Hardware and Operating Systems List at
http://support.intel.com/support/ motherboards/server for a list of supported
drives and/or operating systems. The boot drives can be used as either SATA or
SAS drives and are connected to the SAS 0 and SAS 1 ports on the server board.
The software RAID on the server board can be used to setup the drives installed in
the boot drive module. Refer to the Intel Server Board S5000PSL User Guide for
information on setting up the server board to support either SATA or SAS options.
See “Setting up RAID on the Intel Storage Server SSR212MC2R” on page 137 for
information on setting up RAID 0 or RAID 1 options using these boot drives.
The twelve drives connected to the storage array backplane are controlled by the
Intel RAID Controller SRCSATAWB. See the Intel RAID Controller SRCSATAWB
Software User Guide and Hardware Guide for information on configuring RAID
options. See “Setting up RAID on the Intel Storage Server SSR212MC2R” on page
137 for instructions on setting up virtual disks on the Intel Storage Server SSR2 1
2MC2R. If desired, operating systems can be loaded onto drives connected to the
Intel RAID Controller SRCSATAWB, stored on boot drives or loaded on a USB or
SATA DOM.
See your operating system or third-party storage software documentation for
instructions on loading drivers and configuring the storage server.
Table 15. Intel Storage Server SSR212MC2R Boot Drive Cable Connections
Boot drive options Mini-USB cable P4 power cable Boot drives 12 SAS/SATA drives
SATA drives only on
boot drive module
Connected to
mini-USB connector
on server board
Connected to boot
drive module
backplane
SATA 0 connected to
bottom SATA drive.
SATA 1 connected to
top SATA drive
Intel RAID Controller
SRCSATAWB
connected to
backplane via
mini-SAS to
mini-SATA cable
Chapter 8. Features 79
