Nugget 500 Series Valves
Inline Valves
Pilot
Port Pressure Weight Repair
Description Symbol Type Size Body Operator psig (bar) lbs. (kg) Kit
5-port/2-position
1/2" PTF MN01CGA 33-A000
40 - 150 1.16
54677-50
Single Air single pressure (2.8 - 10.3) (.53)
Spring Return* 5-port/2-position
1/2" PTF MN02CGA 33-A000
40 - 150 1.16
54677-51
dual pressure (2.8 - 10.3) (.53)
5-port/2-position
1/2" PTF MN01CGA 23-A000
20 - 150 1.16
54677-50
Double single pressure (1.4 - 10.3) (.53)
Air 5-port/2-position
1/2" PTF MN02CGA 23-A000
20 - 150 1.16
54677-51
dual pressure (1.4 - 10.3) (.53)
5-port/2 position
1/2" PTF MN01CGA 23-B000
30 - 150 1.42
54677-50
Double Air single pressure (2.1 - 10.3) (.65)
Detent 5-port/2 position
1/2" PTF MN02CGA 23-B000
30 - 150 1.42
54677-51
dual pressure (2.1 - 10.3) (.65)
5-port/3-position
single pressure,
1/2" PTF MN03CGA 23-F000
40 - 150 1.42
54677-52
all ports blocked in (2.8 - 10.3) (.65)
Double Air,
center position
Spring Centered,
5-port/3-position
1/2" PTF MN04CGA 23-F000
40 - 150 1.42 54677-53
all ports blocked
dual pressure,
(2.8 - 10.3) (.65) all ports blocked in
center position
5-port/3-position
1/2" PTF MN05CGA 23-F000 20 - 150 1.42 54677-54
Double Air
single pressure,
(1.4 - 10.3) (.65)
Spring Centered
cylinder open to
Cylinder Open
exhaust
to Exhaust 5-port/3-position dual
1/2" PTF MN06CGA 23-F000
20 - 150 1.42
54677-55
pressure, cylinder (1.4 - 10.3) (.65)
open to exhaust
2 4
3 1 5
4 2
3 1 5
2 4
3 1 5
2
4
3 1 5
2
4
3 1 5
2 4
3 1 5
2 4
1 5 3
2 4
1 5 3
2 4
1 5 3
* Standard valves are equipped with PTF threads..
Note: For ISO-G threads, insert “G” in the 7th position.
2 4
1 5 3
