Nugget 500 Series Valves
Specifications
Operating Specifications
Fluids: Filtered, lubricated or nonlubricated, compressed air or vacuum service.
Inlet Pressure Range:
Solenoid Operated Valves:*
With Internal Pilot Supply:
20 to 150 psig (1.4 to 10.3 bar)
With External Pilot Supply:
26" Hg** to 150 psig
(26" Hg** to 10.3 bar)
Air Operated Valves: 26" Hg** to 150 psig (26" Hg** to 10.3 bar).
Temperature Range (Ambient & Inlet):
Solenoid Operated Valves: -20°F to 120°F † (-29°C to 50°C).
Air Operated Valves: -20°F to 160°F †
(-29°C to 71°C).
Operator Pilot Pressures:
Maximum Pressure: 150 psig (10.3 bar)
Minimum Pressure requirements are given in the table below:
* Solenoid operators must be externally piloted if the supply pressure to the main
valve is below the minimum pilot pressure listed in the table below.
** With vacuum supply plumbed to an exhaust port.
†With dewpoint of supply air less than air temperature below 35°F (2°C).
Port Size (PTF Standard, ISO Optional)
Inline Valves: 3/8" & 1/2" PTF standard, (ISO G optional); 3/4" PTF only
Inline Valve Fixed Length Manifold: 3/4" PTF inlet and exhaust ports standard
(ISO G optional).
Single Subbase: 3/8" or 1/2" PTF standard (ISO G optional); 1/8" PTF or ISO G
external pilot supply.
Manifolding Subbase: 3/8" or 1/2" PTF standard (ISO G optional) cylinder
ports.
End Plates for Manifolding Subbases: 3/4" PTF standard (ISO G optional) inlet
and exhaust ports;
1/8" PTF or ISO G external pilot supply.
Operator: 1/8" PTF or ISO G external pilot supply port.
Special Order Threads: ISO Rc – Consult Factory.
Valve Materials
Body: Aluminum
Spool: Aluminum
Elastomers: Nitrile
Solenoid Operator Base: PPS Plastic
Operator Housing: Zinc
Speed Control Materials
Body: Zinc
Adjusting Screw: Brass
Elastomers: Nitrile
Subbase Materials
Fixed Length Manifold: Aluminum
Single & Manifolding Subbases: Aluminum
End Plate: Zinc
Elastomers: Nitrile
Solenoid Operator Specifications
Voltages and Power Requirements:
Standard:
120V/60Hz-110V/50Hz: 3.5W.
Optional:
24V/60Hz-24V/50Hz: 3.5W;
6 VDC: 2.0W;
12 VDC: 2.0W;
24 VDC: 2.0W;
110 VDC: 3.4W.
120V/60Hz-110V/50Hz: 7.5W;
240V/60Hz-220V/50Hz: 7.5W;
24V/60Hz-24V/50Hz: 7.5W;
12 VDC: 7.5W;
24 VDC: 6.0W.
Duty: Continuous at 90 to 105 % of rated voltage.
Coil Type: Class H. Molded with three-pin electrical plug-
in connector.
Enclosure Classification: NEMA 4, and DIN 40050-IP65.
Electrical spade connections on the operator receptacle
conform to industry standard form B for 3-pin
connectors with 11 mm spacing.
Electrical Plug-in Connector: Cable grip for cables 1/4"
to 5/16" (6 to 8 mm) in diameter.
Override: Non-locking, locking or no override
External Pilot Supply Port: 1/8" PTF or ISO G
Average Flow Factor (Cv) †
3/8", 1/2", & 3/4" Ported Valves: 4.0, 5.0, & 5.6,
respectively.
† Flow rating determined in accordance with ANSI
(NFPA).T3.21.3, Pneumatic fluid power – Flow test
procedure and reporting method – for fixed orifice
components.
Operator Pilot Pressures
Maximum Pressure: 150 psig (10.3 bar)
Minimum Pilot Pressures are given in the following table
Minimum Operating Pressure
Primary Secondary Nondetent Detent Spring Centered
Operator Return Oper psig (bar) psig (bar) psig (bar)
Air Air 20 (1.4) 30 (2.1) 40 (2.8)
Solenoid Solenoid 20 (1.4) 30 (2.1) 40 (2.8)
Solenoid Spring 40 (2.8) — —
Solenoid Air-Assisted Spring 40 (2.8) — —
Solenoid Integral Air 40 (2.8) — —
Air Spring 40 (2.8) — —
Air Air-Assisted Spring 40 (2.8) — —
Air Integral Air 40 (2.8) — —
