Single Solenoid, Spring Return
5-Port/2-Position:
Nondetent ........MN01D0A-35-ALJA
Nugget 500 Series Valves
Double Solenoid
5-Port/2-Position:
Nondetent .............MN01D0A-25-ALJA
Detent ...................MN01D0A-25-BLJA
5-Port/3-Position:
All Ports Blocked...MN03D0A-25-FLJA
Cylinder Open to
Exhaust.................MN05D0A-25-FLJA
Manifolding Subbase for Subbase
Valve
3/8 PTF ..........................................13335-50
3/8 ISO G .......................................13335-51
1/2 PTF ..........................................13335-52
1/2 ISO G .......................................13335-53
Single Subbase for Subbase Valve
3/8 PTF ...........................................13340-70
3/8 ISO G........................................13340-71
1/2 PTF ...........................................13340-72
1/2 ISO G........................................13340-73
Double Air
5-Port/2-Position:
Nondetent ................MN01D0A-23-A000
Detent ......................MN01D0A-23-B000
5-Port/3-Position:
All Ports Blocked ......MN03D0A-23-F000
Cylinder Open to
Exhaust ....................MN05D0A-23-F000
Single Air, Spring Return
5-Port/2-Position:
Nondetent ........MN01D0A-33-A000
Subbase Valves with Operators without Subbase
Note: Mounting screws and gaskets are included.
