DS470F4 7
CS8415A
DIGITAL INPUT CHARACTERISTICS
DIGITAL INTERFACE SPECIFICATIONS
AGND = DGND = 0 V; all voltages with respect to 0 V.
5. At 5.0 V mode, V
IL
= 0.8 V (Max), at 3.3 V mode, V
IL
=0.4 V (Max).
SWITCHING CHARACTERISTICS
Inputs: Logic 0 = 0 V, Logic 1 = VL+; C
L
= 20 pF.
6. Cycle-to-cycle using 32 to 96 kHz external PLL filter components.
Parameters Symbol Min Typ Max Units
Input Leakage Current I
in
- ±1 ±10 µA
Differential Input Voltage, RXP0 to RXN0 V
TH
- 200 - mV
Parameters Symbol Min Max Units
High-Level Output Voltage (I
OH
= -3.2 mA) V
OH
(VL+) - 1.0 - V
Low-Level Output Voltage (I
OH
= 3.2 mA) V
OL
- 0.4 V
High-Level Input Voltage, except RX
n
V
IH
2.0 (VL+) + 0.3 V
Low-Level Input Voltage, except RX
n
(Note 5) V
IL
-0.3 0.4/0.8 V
Parameter Symbol Min Typ Max Units
RST pin Low Pulse Width 200 - -
µs
PLL Clock Recovery Sample Rate Range 8.0 - 108.0 kHz
RMCK output jitter (Note 6) - 200 - ps RMS
RMCK output duty cycle 40 50 60 %
